| Engine | |
| Max Power | 6.4 KW / 6,750 RPM |
| Max Torque | 10.00 NM / 5,500 RPM |
| Engine Type | 4-STROKE, 1- CYLINDER, SOHC, 2-VALVE |
| Bore X Stroke | 52.5 MM X 57.4 MM |
| Engine Displacement |
124 CC
|
| Compression Ratio |
11.5:1
|
| Fuel System | FI |
| Cooling System |
AIR-COOLED
|
| LUBRICATION |
WET SUMP
|
| Starting | KICK AND ELECTRIC |
| Transmission Type | CVT |
| Chassis | |
| Suspension (Front) | TELESCOPIC |
| Suspension (Rear) | HYDRAULIC TYPE |
| Tire Size (Front) | 90/90-12 54J TUBELESS |
| Tire Size (Rear) | 90/100-10 53J TUBELESS |
| Brakes (Front) |
DISC
|
| Brakes (Rear) |
DRUM
|
| Fuel Tank Capacity |
5.2 L
|
| Dimensions | |
| Overall Length | 1,895 MM |
| Overall Width | 710 MM |
| Overall Height | 1,175MM |
| Wheelbase | 1,265 MM |
| Ground / Road Clearance |
160 MM
|
|
Dry Weight
|
106 KG
|
| Curb Mass | 780 MM |
