| Engine | |
| Max Power | 11,5KW/9,500RPM |
| Max Torque | 12.4 NM / 8,500RPM |
| Engine Type | 4-STROKE, OIL-COOLED, 4-VALVE, DOHC (TWINCAM), 1 CYLINDER |
| Bore X Stroke | 62.0MM X 48.8MM |
| Engine Displacement |
147.3CC
|
| Compression Ratio |
10.2:1
|
| Fuel System | CARBURETOR |
| Lubrication | WET SUMP |
| Cooling System |
AIR-COOLED
|
| Starting | ELECTRIC/KICK |
| Transmission Type | MAN. 6-SPD, CONSTANT MESH |
| Clutch Type (Primary) | HYDRAULIC WITH MULTI LAYER |
| Chassis | |
| Suspension (Front) | TELESCOPIC, COIL SPRING OIL DAMPED |
| Suspension (Rear) | SWINGARM WITH MONO SHOCK UP |
| Tire Size (Front) | 70/90 – 17 38P (TUBELESS TYPE) |
| Tire Size (Rear) | 80/90 – 17 44P (TUBELESS TYPE) |
| Brakes (Front) |
DISC
|
| Brakes (Rear) |
DISC
|
| Dimensions | |
| Overall Length | 1,945MM |
| Overall Width | 670MM |
| Overall Height | 980MM |
| Wheelbase | 1,280MM |
| Ground / Road Clearance |
140MM
|
| Dry Weight |
107KG
|
| Seat Height | 764MM |
