| Engine Type | Air cooled, 4-stroke, SOHC, 2-valve |
| Cylinder arrangement | Single Cylinder |
| Displacement | 125 cm³ |
| Ignition System | |
| Bore & stroke | 52.4mm x 57.9mm |
| Compression ratio |
9.5:1
|
| Maximum horse power | 7.0kW(9.4PS)/8000r/min |
| Maximum torque | 9.6N･m(1.0kgf･m)5500r/min |
|
Starting system
|
Electric starter and kickstarter |
| Lubrication system | Force-feed lubrication,wet sump |
| Engine oil capacity | 0.8L |
| Fuel supply system | Fuel injection |
| Clutch type | Dry, Centrifugal |
| Transmission type | V-Belt Automatic |
| CHASSIS | |
| Frame type | Underbone |
| Front suspension | Telescopic Fork |
| Rear suspension | Unit Swing |
| Front tire |
80/80R14M/C 43P Tube type
|
| Rear tire | 100/70-14M/C 51P(Tubeless) |
| Front brake |
Hydraulic disc brake
|
| Rear brake |
Mechanical leading trailing shoe brake（Drum brake）
|
| ELECTRICAL | |
| Ignition system type | TCI(Transistor controlled ignition) |
| Battery | YTZ4V, GTZ4V, NTZ4V |
| Headlight | LED /12V, 7.6W x1 (hi-beam) | LED /12V, 5.1W x1 (lo-beam) |
| Tail light |
12V,21/5W×1 12V,21/5Wx1
|
| DIMENSION | |
| Overall length x width x height | 1,870mm X 685mm X 1,060mm |
| Seat height | 750mm |
| Wheelbase | 1,260mm |
| Minimum ground clearance |
135 mm
|
| Wet weight (with oil and a full fuel tank) | Mio Gear – 95kg / Mio Gear S – 96kg |
| Fuel tank capacity |
4.2L
|
| STANDARD EQUIPMENT | |
| Meter panel | Analogue |
| Stop & start system | Equipped (for S version only) |
