| Engine Type | Liquid cooled, 4-stroke, SOHC, 4-valve |
| Cylinder arrangement | Single cylinder |
| Displacement | 155 cm3 |
| Bore & stroke | 58.0×58.7mm |
| Compression ratio |
10.5:1
|
| Maximum horse power |
13.2kW(17.9PS)/9500r/min
|
| Maximum torque | 14.4N・m(1.5kgf・m)/8000r/min |
|
Starting system
|
Electric starter |
| Lubrication system | Wet sump |
| Engine oil capacity | 1.10 L |
| Fuel supply system | Fuel Injection |
| Clutch type | Wet, Multiple-disc |
| Transmission type | Constant Mesh, 6-Speed |
| CHASSIS | |
| Frame type | Backbone |
| Front suspension | Telescopic Fork |
| Rear suspension | Swingarm |
| Front tire |
90/80-17M/C 46P Tubeless
|
| Rear tire | 120/70-17M/C 58P Tubeless |
| Front brake |
Hydraulic single disc brake (2-pot brake Caliper for R version)
|
| Rear brake |
Hydraulic single disc brake
|
| ELECTRICAL | |
| Ignition system type | TCI(Transistor controlled ignition) |
| Battery | GTZ5S |
| Headlight | LED |
| Tail light |
LED
|
| DIMENSION | |
| Overall length x width x height | 1975mm X 665mm X 1085mm |
| Seat height | 795mm |
| Wheelbase | 1290mm |
| Minimum ground clearance |
150mm
|
| Wet weight (with oil and a full fuel tank) | 119kg, 121kg R version |
| Fuel tank capacity |
5.4L
|
| STANDARD EQUIPMENT | |
| Meter panel | Digital |
| Assist & slipper clutch | Equipped |
