₱182,900.00
6 in stock
For cash purchase just message us at our Facebook Page : DES APPLIANCE PLAZA, INC
| Engine Type | Liquid cooled, 4-stroke, SOHC, 4-valve |
| Cylinder arrangement | Single cylinder |
| Displacement | 155cm3 |
| Bore & stroke | 58.0 × 58.7mm |
| Compression ratio |
11.6:1
|
| Maximum horse power |
12.3kW (16.7PS) / 10000r/min
|
| Maximum torque | 14.3 N.m (1.5 kgf.m) / 6500r/min |
|
Starting system
|
Electric starter |
| Lubrication system | Wet sump |
| Engine oil capacity | 1.10L |
| Fuel supply system | Fuel Injection |
| Clutch type | Wet, Multiple-disc |
| Transmission type | Constant Mesh, 6-Speed |
| CHASSIS | |
| Frame type | Semi double cradle |
| Front suspension | Telescopic fork |
| Rear suspension | Swingarm (Link suspension) |
| Front tire |
2.75 – 21 45P Tube type
|
| Rear tire | 4.10 – 18 59P Tube type |
| Front brake |
Hydraulic single disc brake
|
| Rear brake |
Hydraulic single disc brake
|
| ELECTRICAL | |
| Ignition system type | TCI (Transistor Controlled Ignition) |
| Battery | YTZ4V / GTZ4V |
| Headlight | 12V 35W / 35W × 1 |
| Tail light |
12V 18W / 5W × 1
|
| DIMENSION | |
| Overall length x width x height | 2145 mm X 840 mm X 1200 mm |
| Seat height | 880 mm |
| Wheelbase | 1380mm |
| Minimum ground clearance |
160mm
|
| Wet weight (with oil and a full fuel tank) |
169kg
|
| Fuel tank capacity |
14L
|
| STANDARD EQUIPMENT | |
| Meter panel | Fully digital |
