The YZF-R15M redefines innovation on the racetrack. A highly precise machine that has been crafted for superior performance, advance with the latest technology, and designed true to the R brand. Now enhanced with Y-Connect compatibility, linking you with your motorcycle for a whole new experience.
| SPECIFICATIONS | |
|
Make |
YAMAHA- Revs your Heart.
|
|
Model |
YAMAHA YZF-R15
|
|
Transmission |
Manual
|
|
Fuel Capacity |
11 L
|
|
Clutch Type |
Wet, Multiple-Disc
|
|
Lubrication System |
Wet Sump
|
|
Transmission Type |
Constant Mesh, 6-Speed
|
|
Ignition Type |
TCI (Transistor Controlled Ignition)
|
|
Bore x Stroke (mm) |
58.0 x 58.7 mm
|
|
Engine Type |
Liquid Cooled 4-Stroke, SOHC, 4-valve
|
|
Frame Type |
Diamond
|
|
Seat Height |
815 mm
|
|
Brake System (Front/Rear) |
Hydraulic Single Disc Brake
|
|
Displacement (cc) |
155 cm3
|
|
Front Suspension |
Upside Down Telescopic Fork
|
|
Engine Oil Capacity (L) |
1.05 L
|
|
Front Tire |
100/80-17M/C 52P Tubeless
|
|
Starting System |
Electric Starter
|
|
Wet Weight (with oil & fuel) |
137 kg
|
|
Maximum Horse Power |
14.2kW(19.3PS) / 10000r / min
|
|
Maximum Torque |
14.7N・m(1.5kgf・m)/ 8500r / min
|
|
Compression Ratio |
11.6:1
|
|
Rear Suspension |
Swingarm (Link Suspension)
|
|
Rear Tire |
140/70-17M/C 66S Tubeless
|
|
Overall Dimensions (length x width x height) |
1990 mm x 725 mm x 1135 mm
|
|
Wheelbase |
1325 mm
|
|
Minimum Ground Clearance |
170 mm
|
|
Cylinder Arrangement |
Single Cylinder
|
|
Fuel System |
Fuel Injection
|
|
Headlight |
LED
|
|
Tailight |
LED
|
