Description

The Yamaha YZF-R3 B5LX is a variant of Yamaha’s popular entry-level sportbike, the YZF-R3. While specific details about the B5LX designation are limited, the general specifications and features of the YZF-R3 can provide insight into this model.

🏍️ Yamaha YZF-R3 B5LX – Specifications & Features

Engine & Performance

• Engine Type: 321cc liquid-cooled, 4-stroke, DOHC inline twin-cylinder

• Power Output: Approximately 41.4 hp @ 10,750 rpm

• Torque: 29.6 Nm @ 9,000 rpm

• Compression Ratio: 11.2:1

• Fuel System: Fuel injection

• Transmission: 6-speed manual with Assist & Slipper clutch

• Top Speed: Approximately 170 km/h

• Fuel Economy: Around 25–29 km/L Yamaha Motorsports

Chassis & Suspension

• Frame: Diamond-type steel frame

• Front Suspension: Inverted telescopic fork (USD)

• Rear Suspension: Monocross single shock with preload adjustability

• Front Brake: 298mm hydraulic disc with ABS

• Rear Brake: 220mm hydraulic disc with ABS

• Front Tire: 110/70 R17

• Rear Tire: 140/70 R17

Dimensions & Weight

• Length x Width x Height: 2,090 mm x 730 mm x 1,140 mm

• Wheelbase: 1,380 mm

• Seat Height: 780 mm

• Ground Clearance: 160 mm

• Kerb Weight: 169 kg

• Fuel Tank Capacity: 14 liters

Features

• Lighting: LED headlight, tail light, and turn signals

• Instrument Cluster: Digital LCD display

• Connectivity: Yamaha Motorcycle Connect (Y-Connect) smartphone integration

• Additional Features: USB-A charging port, hazard warning lights, gear indicator
