| Engine Type |
4-Stroke, 4-Valve, DOHC, Liquid-Cooled |
| Displacement |
149 cc |
| Bore & Stroke |
57.3 × 57.8 mm |
| Compression Ratio |
11.3 : 1 |
| Maximum Power |
12.0 kW @ 9,000 rpm |
| Maximum Torque |
13.7 Nm @ 7,000 rpm |
| Engine Oil Capacity |
1.3 L |
| Fuel System |
PGM-FI |
| Fuel Consumption |
41.5 km/L (HUDC) |
| Transmission |
Manual, 6-Speed Constant Mesh |
| Gear Shift Pattern |
1-N-2-3-4-5-6 (Down Up) |
| Ignition Type |
Full Transistorized |
| Battery |
12V – 5Ah (MF-WET) |
| Rear Suspension |
Pro-Link |
| Front Brake |
Hydraulic Disc |
| Rear Brake |
Hydraulic Disc |
| Front Tire |
100/80-17 M/C 52P (Tubeless) |
| Rear Tire |
130/70-17 M/C 62P (Tubeless) |
| Wheel Type |
Cast Wheel |
| Overall Dimensions (L × W × H) |
1,983 × 700 × 1,090 mm |
| Curb Weight |
138 kg |
| Seat Height |
788 mm |
| Wheelbase |
1,310 mm |
| Ground Clearance |
151 mm |
| Fuel Tank Capacity |
12.0 L |
| Meter Panel |
Liquid Crystal Display (LCD) |
| Key System |
Mechanical Key |
| Lighting System |
All LED Lighting |
| Anti-lock Braking System (ABS) |
Equipped (2-Channel) |
| Bank Angle Sensor |
Equipped |
